SPECIFICATIONS

Dimension

178 x 83 x 17mm

Weight

580 g

Color

Front shell: black, Bottom shell: black

Display

5.72" (720 x 1440 pixels)

Touchscreen

Multi-touch panel, corning glass grade 3

Camera

Front: 5MP (optional), Rear: 13MP+AF+flash

Speaker

Built-in 8Ω/0.8W waterproof horn

Microphone

Sensitivity: -42db, output impedance 2.2kΩ

Battery

Polymer lithium ion 1000mAh/3.7V (non removable)

Battery Life

About 8 hours (standby time >300h)

CPU

MTK 6762 Octa-core 2.0 Ghz

RAM

3GB (2GB/4GB optional)

ROM

32GB (16GB/64GB optional)

O.S

Android 12

Communication

2G/3G/4G, Dual-band Wifi 2.4G+5G 802.11 b/g/n/a/ac, Bluetooth 5.0 (BLE)

GPS

Built-in GPS

NFC

Support ISO/IEC 14443A protocol, card reading distance: 3-5 cm

Fingerprint

Capacitive USB press module, image size：256*360 px

FBI PIV FAP10 certification Image resolution：508 dpi

Acquisition speed: single frame image ≤0.25s

QR Code

Honeywell 6603 & Zebra SE4710 & CM60

Optical resolution: 5mil

Scanning speed: 50 times/s

Support code type: PDF417, MicroPDF417, Data Matrix,

Data Matrix Inverse, Maxicode, QR Code, MicroQR,

QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse

RFID

LF: support 125k and 134.2k, effective recognition distance 3-5 cm

HF: 13.56Mhz, support 14443A/B; 15693 agreement, effective recognition distance 3-5cm

UHF: CHN freq 920-925 Mhz, US freq 902-928 Mhz, EU freq 865-868 MHz

Protocol Std. : EPC C1 Gen2/ISO 18000-6C

Antenna parameter: spiral antenna (4dbi) card reading distance according to different labels, effective distance 1-6m

Biometric: ID card identification, fingerprint acqusition, face recognition
