SPECIFICATIONS

Dimension: 178 x 83 x 17mm

Weight: 300 g

Color: Front shell: black, Bottom shell: black

Display: 5.72" (720 x 1440 pixels)

Touchscreen: Multi-touch panel, corning glass grade 3

Camera: Front: 5MP (optional), Rear: 13MP+AF+flash

Speaker: Built-in 8Ω/0.8W waterproof horn

Microphone: Sensitivity: -42db, output impedance 2.2kΩ

Battery: Polymer lithium ion 1000mAh/3.7V (non removable)

Battery Life: About 8 hours (standby time >300h)

CPU: MTK 6762 Octa-core 2.0 Ghz

RAM: 3GB (2GB/4GB optional)

ROM: 32GB (16GB/64GB optional)

O.S: Android 12

Communication: 2G/3G/4G, Dual-band Wifi 2.4G+5G 802.11 b/g/n/a/ac, Bluetooth 5.0 (BLE)

GPS: Built-in GPS

NFC: Support ISO/IEC 14443A protocol, card reading distance: 3-5 cm

Fingerprint: Capacitive USB press module, image size：256*360 px, FBI PIV FAP10 certification Image resolution：508 dpi, acquisition speed: single frame image ≤0.25s

QR Code: Honeywell 6603 & Zebra SE4710 & CM60, optical resolution: 5mil, scanning speed: 50 times/s Support code type: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse

RFID: LF: support 125k and 134.2k, effective recognition distance 3-5 cm HF: 13.56Mhz, support 14443A/B; 15693 agreement, effective recognition distance 3-5cm UHF: CHN freq 920-925 Mhz, US freq 902-928 Mhz, EU freq 865-868 MHz Protocol Std. : EPC C1 Gen2/ISO 18000-6C, Antenna parameter: spiral antenna (4dbi) card reading distance according to different labels, effective distance 1-6m

Infrared Reading: >3.5m reading distance, 35°, comply with DLT 645-2007 (DLT 645-1997)

Biometric: ID card identification, fingerprint acqusition, face recognition
